Type |
|
Type |
Digital, single-lens reflex, AF / AE camera with built-in flash |
Recording media |
SD memory card, SDHC memory card, SDXC memory card |
Image sensor size |
Approx. 22.3 x 14.9mm |
Compatible lenses |
Canon EF lenses (including EF-S lenses)
* Excluding EF-M lenses
(35mm-equivalent angle of view is that of a lens with approx. 1.6x the focal length indicated.) |
Lens mount |
Canon EF mount |
Image Sensor |
|
Type |
CMOS sensor |
Effective pixels |
Approx. 24.1 megapixels |
Aspect ratio |
3:2 |
Dust delete feature |
Dust Delete Data appending, Clean manually |
Recording System |
|
Recording format |
Design rule for Camera File System (DCF) 2.0 |
Image type |
JPEG, RAW (14-bit Canon original)
RAW+JPEG Large simultaneous recording possible |
Pixels recorded |
L (Large): |
Approx. 24 megapixels (6000 x 4000) |
M (Medium): |
Approx. 10.6 megapixels (3984 x 2656) |
S1 (Small 1): |
Approx. 5.9 megapixels (2976 x 1984) |
S2 (Small 2): |
Approx. 2.5 megapixels (1920 x 1280) |
S3 (Small 3): |
Approx. 350,000 pixels (720 x 480) |
RAW: |
Approx. 24 megapixels (6000 x 4000) |
Create / select a folder |
Possible |
File numbering |
Continuous, Auto reset, Manual reset |
Image Processing During Shooting |
|
Picture Style |
Auto, Standard, Portrait, Landscape, Neutral, Faithful, Monochrome, User Def. 1 – 3 |
Basic+ |
Ambience-based shots, Light / scene-based shots |
White balance |
Auto (Ambience priority), Auto (White priority), Preset (Daylight, Shade, Cloudy, Tungsten light, White fluorescent light, Flash), Custom
White balance correction, and White balance bracketing provided* Flash color temperature information transmission enabled |
Noise reduction |
Applicable to long exposures and high ISO speed shots |
Automatic image brightness correction |
Auto Lighting Optimizer |
Highlight tone priority |
Provided |
Lens peripheral illumination correction |
Provided |
Viewfinder |
|
Type |
Eye-level pentamirror |
Coverage |
Vertical / Horizontal approx. 95% (with eyepoint approx. 21mm) |
Magnification |
Approx. 0.8x (-1m-1 with 50mm lens at infinity) |
Eye point |
Approx. 21mm (from eyepiece lens center at -1m-1) |
Standard diopter |
Approx. -2.5 – +0.5m-1 (dpt) |
Focusing screen |
Fixed, Precision Matte |
Mirror |
Quick-return type |
Depth-of-field preview |
Enabled with Custom Function setting |
Autofocus (for viewfinder shooting) |
|
Type |
TTL secondary image-registration, phase-difference detection with the dedicated AF sensor |
AF points |
9-point (All AF points support f/5.6. Cross-type AF with center AF point.) |
Focusing brightness range |
EV 0 – 18 (Center AF point)
EV 1 – 18 (Other AF points)
(With One-Shot AF, at room temperature, ISO 100) |
AF operation |
One-Shot AF, AI Servo AF, AI Focus AF |
AF-assist beam |
Small series of flashes fired by built-in flash |
Exposure Control |
|
Metering modes |
63-zone TTL open-aperture metering
- Evaluative metering (linked to all AF points)
- Partial metering (approx. 10% of viewfinder at center)
- Center-weighted average metering
|
Metering brightness range |
EV 1 – 20 (at room temperature, ISO 100) |
Shooting mode |
Basic Zone modes: |
Scene Intelligent Auto, Flash Off, Creative Auto, Portrait, Landscape, Close-up, Sports, Food, Night Portrait |
Creative Zone modes: |
Program AE, Shutter-priority AE, Aperture-priority AE, Manual exposure |
ISO speed
(Recommended exposure index) |
Basic Zone modes*: |
ISO 100 – 3200 set automatically
* Portrait: ISO 100 |
Creative Zone modes: |
ISO 100 – 6400 set manually (whole-stop increments), ISO 100 – 6400 set automatically, maximum ISO speed settable for ISO Auto, or ISO expansion to “H” (equivalent to ISO 12800) |
Exposure compensation |
Manual: |
±5 stops in 1/3- or 1/2-stop increments |
AEB: |
±2 stops in 1/3- or 1/2-stop increments (can be combined with manual exposure compensation) |
AE lock |
Auto: |
Applied in One-Shot AF with evaluative metering when focus is achieved |
Manual: |
With AE lock button |
Shutter |
|
Type |
Electronically-controlled, focal-plane shutter |
Shutter Speed |
1/4000sec. to 30sec. (Total shutter speed range. Available range varies by shooting mode.), Bulb, X-sync at 1/200sec. |
Flash |
|
Built-in flash |
Retractable, auto pop-up flash |
Guide No.: |
Approx. 9.2 / 30.2 (ISO 100, in meters / feet) or approx. 13 / 42.7 (ISO 200, in meters / feet) |
Flash coverage: |
Approx. 17mm lens angle of view |
Recharge time: |
Approx. 2sec. |
External Speedlite |
Compatible with EX-series Speedlites |
Flash metering: |
E-TTL II autoflash |
Flash exposure compensation |
±2 stops in 1/3- or 1/2-stop increments |
FE lock |
Provided |
PC terminal |
Not provided |
Drive System |
|
Drive modes |
Single shooting, Continuous shooting, Self-timer with 10-sec. or 2-sec. delay and 10-sec. delay with continuous shooting |
Continuous shooting speed |
Max. approx. 3.0 shots/sec. |
Max. burst (Approx.) |
JPEG Large / Fine: |
150 shots |
RAW: |
11 shots |
RAW+JPEG Large / Fine: |
6 shots |
* Figures are based on Canon’s testing standards (ISO 100 and Standard Picture Style) using an 8GB card. |
Live View Shooting |
|
Aspect ratio |
3:2, 4:3, 16:9, 1:1 |
Focus methods |
Contrast detection (FlexiZone-Single, Face detection Live mode), Phase-difference detection (Quick mode)
Manual focus (approx. 5x / 10x magnification possible) |
Focusing brightness range |
EV 1 – 18 (at room temperature, ISO 100) |
Metering mode |
Real-time metering with image sensor |
Metering brightness range |
EV 0 – 20 (at room temperature, ISO 100) |
Grid display |
Two types |
Movie Shooting |
|
Recording format |
MOV |
Movie |
MPEG-4 AVC / H.264
Variable (average) bit rate |
Audio |
Linear PCM |
Recording size and frame rate |
1920 x 1080 (Full HD): |
30p / 25p / 24p |
1280 x 720 (HD): |
60p / 50p |
640 x 480 (SD): |
30p / 25p |
* 30p: 29.97fps, 25p: 25.00fps, 24p: 23.98fps, 60p: 59.94fps, 50p: 50.00fps |
Bit rate |
1920 x 1080 (30p / 25p / 24p): |
Approx. 46Mbps |
1280 x 720 (60p / 50p): |
Approx. 46Mbps |
640 x 480 (30p / 25p): |
Approx. 11Mbps |
Focus method |
Same as focusing with Live View shooting |
Focusing brightness range |
EV 1 – 18 (at room temperature, ISO 100) |
Metering mode |
Center-weighted average and Evaluative metering with the image sensor
* Automatically set by the focus method. |
Metering brightness range |
EV 0 – 20 (at room temperature, ISO 100) |
Exposure control |
Autoexposure and manual exposure |
Exposure compensation |
±3 stops in 1/3-stop increments |
ISO speed
(Recommended exposure index) |
With autoexposure shooting: |
ISO 100 – 6400 set automatically |
With manual exposure: |
ISO 100 – 6400 set automatically / manually |
Video snapshots |
Settable to 2sec. / 4sec. / 8sec. |
Sound recording |
Built-in monaural microphone
Sound-recording level adjustable, wind filter provided |
Grid display |
Two types |
Still photo shooting |
Not possible during movie shooting |
LCD Monitor |
|
Type |
TFT color liquid-crystal monitor |
Monitor size and dots |
Approx. 7.5cm (3.0in.) (4:3) with approx. 920,000 dots |
Brightness adjustment |
Manual (7 levels) |
Interface languages |
25 |
Feature guide |
Displayable |
Playback |
|
Image display format |
Basic info, basic info + image quality / playback number, shooting info. display, histogram, index display (4 / 9) |
Zoom magnification |
Approx. 1.5x – 10x |
Highlight alert |
Overexposed highlights blink |
Image browsing method |
Single image, jump by 10 or 100 images, by shooting date, by folder, by movies, by stills, by rating |
Image rotation |
Possible |
Rating |
Provided |
Movie playback |
Enabled (LCD monitor, HDMI)
Built-in speaker |
Image protect |
Possible |
Slide show |
All images, by date, by folder, by movies, by stills, by rating
Five transition effects selectable |
Background music |
Selectable for slide shows and movie playback |
Post-Processing of Images |
|
Creative filters |
Grainy B/W, Soft focus, Fish-eye effect, Toy camera effect, Miniature effect |
Resize |
Possible |
Direct Printing |
|
Compatible printers |
PictBridge-compatible printers |
Printable images |
JPEG and RAW images |
Print Ordering |
DPOF Version 1.1 compatible |
Wireless Communications |
|
Standards compliance |
IEEE 802.11b/g/n |
Transmission method |
DS-SS modulation (IEEE 802.11b)
OFDM modulation (IEEE 802.11g/n) |
Transmission range |
Approx. 15m / 49.2ft.
*When communicating with a smartphone
*With no obstructions between the transmitting and receiving antennas and no radio interference |
Transmission frequency (central frequency) |
Frequency: 2412 to 2462 MHz
Channels: 1 to 11 ch |
Connection method |
Camera access point mode, infrastructure*
* Wi-Fi Protected Setup supported |
Security |
Authentication method: Open system, Shared key, WPA / WPA2-PSK
Encryption: WEP, TKIP, AES |
NFC connection |
For communication with smartphones or connection to Connect Station |
Wi-Fi Functions |
|
Communication with a smartphone |
Images can be viewed, controlled, and received using a smartphone.
Remote control of the camera using a smartphone is possible. |
Transfer images between cameras |
Transferring one image, Transferring selected images, Transferring resized images |
Connect to Connect Station |
Images can be sent to and saved on Connect Station. |
Print from Wi-Fi printers |
Images can be sent to a Wi-Fi printer. |
Send images to a Web service |
Images in the camera or links to images can be sent to registered Web services. |
Customization Features |
|
Custom Functions |
11 |
My Menu |
Possible |
Copyright information |
Text entry and appending possible |
Interface |
|
DIGITAL terminal |
Hi-Speed USB equivalent: Computer communication,
Direct printing, GPS Receiver GP-E2, Connect Station CS100 connection |
HDMI mini OUT terminal |
Type C (Auto switching of resolution) |
Remote control terminal |
For Remote Switch RS-60E3 |
Eye-Fi card |
Compatible |
Power |
|
Battery |
Battery Pack LP-E10 (Quantity 1)
* AC power can be supplied via household power outlet accessories. |
Number of possible shots
(Based on CIPA testing standards, with 50% flash use) |
With viewfinder shooting: |
Approx. 500 shots at room temperature (23°C / 73°F), Approx. 410 shots at low temperatures (0°C / 32°F) |
With Live View shooting: |
Approx. 240 shots at room temperature (23°C / 73°F), Approx. 230 shots at low temperatures (0°C / 32°F)
• With a fully-charged Battery Pack LP-E10. |
Movie shooting time |
Approx. 1 hr. 30 min. at room temperature (23°C / 73°F)
Approx. 1 hr. 25 min. at low temperatures (0°C / 32°F)
* With a fully-charged Battery Pack LP-E10. |
Dimensions and Weight |
|
Dimensions (W x H x D) |
Approx. 129.0 x 101.3 x 77.6mm / 5.08 x 3.99 x 3.06in. |
Weight |
Approx. 475g / 16.75oz. (Including battery and card),
Approx. 427g / 15.06oz. (Body only) |
Operation Environment |
|
Working temperature range |
0°C – 40°C / 32°F – 104°F |
Working humidity |
85% or less |
